MrCool Universal Series Service Manual

mrcool.com 4
4
Model MDPH180484 MDPH180604
Capacity
Cooling
kW 13.77 16.41
BTU/h 47000 56000
Heating
kW 13.77 16.71
BTU/h 47000 57000
SEER - 17.8 17
HSPF - 8.5 8.3
EER (Btu/h)/W 11 10.6
COP W/W 3.24 3.18
Power Supply V/Ph/Hz 208/230/1/60 208/230/1/60
MOP A 45 45
MCA A 39.1 39.1
Refrigerant Charge Volume lbs 14.8 14.8
Sound Pressure Volume dB(A) 68 68
Dimension
(WxDxH)
Outline in 44-1/8 x 44-1/8 x 49-3/16 44-1/8 x 44-1/8 x 49-3/16
Package in 44-5/8 x 44-5/8 x 50-13/16 44-5/8 x 44-5/8 x 50-13/16
Net Weight/Gross Weight lbs 628/650 628/650
Loading
Quantity
40'GP/40'HQ unit 20/40 20/40
NOTE
• The cooling capacity stated above is measured under the following conditions:
Indoor Conditions: 80.1°F DB / 66.9°F WB (26.7°C DB / 19.4°C WB)
Outdoor Conditions: 95°F DB / 76°F WB (35°C DB / 24°C WB)
• The heating capacity stated above is measured under the following conditions:
Indoor Conditions: 70°F DB / 60°F WB (21.1°C DB / 15.6°C WB)
Outdoor Conditions 46.9°F DB / 42.9°F WB (8.3°C DB / 6.1°C WB)
• The air volume is measured at the relevant standard external static pressure.
• The technical parameters can change as the product improves. Refer to the nameplate on the unit for
actual data.
• Above data is subject to change without notice.
Operating Mode Outdoor Condition °F (°C)
Cooling 23°F ~ 125.6°F (-5°C ~ 52°C)
Heating -22°F ~ 75.2°F (-30 ~ 24°C)
1.5 Operating Range
PRODUCT OVERVIEW
1

MrCool Universal Series Specifications

General

Type	Inverter
Brand	MrCool
Series	Universal Series
Refrigerant	R410A
Phase	1
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Compatibility	Universal
HSPF Rating	10
Voltage	208/230V
Operating Temperature (Cooling)	Varies by model
Operating Temperature (Heating)	Varies by model
Indoor Noise Level (dB)	Varies by model
Outdoor Noise Level (dB)	Varies by model
Indoor Unit Dimensions (H x W x D)	Varies by model
Outdoor Unit Dimensions (H x W x D)	Varies by model
Indoor Unit Weight	Varies by model
Warranty	5 years
