MrCool Universal Series Service Manual

mrcool.com 24
24
UNIT INSTALLATION
3
Model A B C D
MDPH180484
MDPH180604
49-1/4 (1250) 44 (1120) 44 (1120) 2-1/2 (65)
Side Air Vents
E
Size of Air Return
G I
Size of Air Supply
K
F H J L
4 (101)
15-3/8
(30)
16-1/2
(420)
3-3/8 (87) 4 (101)
15-3/8
(390)
11-3/4
(300)
6-1/2
(166)
Bottom Air Vents
M
Size of Air Return
O R
Size of Air Supply
S
N P Q T
7-7/8
(199)
28 (711) 9 (228) 3-3/4 (96)
6-1/2
(166)
11-3/4
(300)
15-3/8
(390)
4 (103)
Unit: inch (mm)
NOTE
Above diagrams may be dierent from actual model.
3.6 Clearance Requirements
Installation Clearances:
in(mm)
1 24 (600)
2 43 (1100)
3 34 (860)
4 43 (1100)
5 60 (1524)
NOTE
Above diagrams may be dierent from actual model.

MrCool Universal Series Specifications

General

Type	Inverter
Brand	MrCool
Series	Universal Series
Refrigerant	R410A
Phase	1
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Compatibility	Universal
HSPF Rating	10
Voltage	208/230V
Operating Temperature (Cooling)	Varies by model
Operating Temperature (Heating)	Varies by model
Indoor Noise Level (dB)	Varies by model
Outdoor Noise Level (dB)	Varies by model
Indoor Unit Dimensions (H x W x D)	Varies by model
Outdoor Unit Dimensions (H x W x D)	Varies by model
Indoor Unit Weight	Varies by model
Warranty	5 years
