MrCool Universal Series Service Manual

mrcool.com 72
72
MAINTENANCE
4
No. Name Code Qty
27 Radiator 43003406003306 1
28 Fan Board 300094000052 1
29 Terminal Board 42200006001202 1
30 Terminal Board 4201025502 1
31 Terminal Board 42200006005405 1
32 Main Board 300027063061 1
33 Transformer 43110286 1
34 Terminal Board 42011103 1
35 Terminal Board 42011147 1
36 Electric Box Assembly 100002078181 1
37 Filter Sub Assembly 111001060400 2
38 Choke Plug 76718209 1
39 Water Tray 012122061115 1
40 Drainage Hose 012146060040 1
41 Brush-less DC Motor 15010400001303 1
42 Centrifugal Fan Housing 1570220301 1
43 Rear Grill 01600106012101 1
44 Filter Sub Assembly 111001060370 1
45 Display Board 300001000204 1
46 Sensor Sub Assembly 390002060379 1
47 Electrical Heater (Compressor) 7651521216 1
48 Electric Expand Valve Fitting 07200206002342 1
49 4 Way Valve Coil 07201006000601 1
50 Electronic Expansion Valve 072009060011 1
51 Plate-Type Heat Exchanger 00904100004 1

MrCool Universal Series Specifications

General

Type	Inverter
Brand	MrCool
Series	Universal Series
Refrigerant	R410A
Phase	1
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Compatibility	Universal
HSPF Rating	10
Voltage	208/230V
Operating Temperature (Cooling)	Varies by model
Operating Temperature (Heating)	Varies by model
Indoor Noise Level (dB)	Varies by model
Outdoor Noise Level (dB)	Varies by model
Indoor Unit Dimensions (H x W x D)	Varies by model
Outdoor Unit Dimensions (H x W x D)	Varies by model
Indoor Unit Weight	Varies by model
Warranty	5 years
