Description
GB
Model 9010/9020 SIL
2.1 Front Panel
Depending on configuration, there are 2 different front panels available for
9010 Module (1 display unit) and 9020 module (2 display units).
Fig. 3 9010 Fig. 4 9020
1 Status LEDs (red/yellow) 5 Site Information Tag
2 System Failure LED (yellow) 6 Display
3 POWER LED (green) 7 Keypad
4 Gas Information Tag 8 Approval label
1
6
2
3
4
5
7
8
