24
Installation
GB
Model 9010/9020 SIL
Connectable Detectors and Transmitters
The following types of active and passive MSA detectors can be connected to the 9010/9020 SIL
unit:
*Performance compliance with EN 60079-29-1 for individual detector / transmitter was tested by notified body
For information about specific gases and vapours to be detected refer to instruction manual of indi-
vidual detectors.
Check Fig. 10 and Fig. 11 to identify the detector connection terminals. For further information of
individual detectors connection check chapter 12.5.
Designation
Measuring
Principle
Use Passive detector
4-20 mA
Transmitter
Series 47K* Catalytic EX X
D-7100 Catalytic EX X
D-7010 Catalytic EX X
DF-7100 Catalytic EX X
DF-7010 Catalytic EX X
DF-9200 Electrochemical TOX/OX X
DF-9500 Electrochemical TOX/OX X
DF-8510 Electrochemical Fire Detection X
Ultima XE* Various EX/TOX/OX X
Ultima XIR* Infrared EX X
Prima X* Various EX/TOX/OX X
PrimaX IR* Infrared EX X
FlameGard 5 MSIR Infrared Flame X
FlameGard 5 UV/IR
Ultraviolet/
Infrared
Flame X
FlameGard 5 UV/IR-E
Ultraviolet/
Infrared
Flame X
Ultima MOS-5 Semiconductor TOX X
Ultima MOS-5E Semiconductor TOX X
Ultima OPIR 5 Infrared EX X
UltraSonic EX-5 Acoustic Leakage X
UltraSonic IS-5 Acoustic Leakage X
