Settings Parameters
GB
Model 9010/9020 SIL
P5
Display Module Parameters
Display the following information in automatic
sequence:
General Information
• Device Type (9010/9020)
• Firmware Version (Fx.y)
• Firmware Build
• ATEX Mode
Individual for each channel
• Offset Value (0-9000)
• Full Scale Value (1-9000)
• Detector Current (100 - 450 mA)
• Caution Threshold Value (0-9000)
• Caution Direction (u/d)
• Caution Reset Mode (1A, 1M, 2A, 2M)
• Caution Output Status (E / dE)
• Caution Delay Set (0-600 s)
• Warning Threshold Value (0-9000)
• Warning Direction (u / d)
• Warning Reset Mode (1A, 1M, 2A, 2M)
• Warning Output Status (E / dE)
• Warning Mode (norM / Stel / TWA)
• Warning Delay Set (0-600 s)
• Alarm Threshold Value (0-9000)
• Alarm Direction (u / d)
• Alarm Reset Mode (1A, 1M, 2A, 2M)
• Alarm Output Status (E / dE)
• Alarm Mode (norM / Stel / TWA)
• Alarm Delay Set (0-600 s)
• *Caution Function (1-13)
• Analog Output Set in normal operation (0-20 / 4-20
/ 20-0 /, 20-4)
• *Horn Function (1-13)
• Horn Output Status (E / dE)
• *Failure Function (1-5)
• Failure Output Status (E / dE)
• Analog Output Set in failure state (0 / 2 / 3 / 4 / 20
/ H)
Press Enter/Up/Down key to
display next item immediately.
Press ESC key to skip.
*Caution, Horn and Failure func-
tions are set during manufac-
turing process and cannot be
changed by user.
Caution, Horn and Failure func-
tions are set to 1 as default for
ATEX mode.
P6
View STEL / TWA "WARNING" Thresholds Values
Displays the average STEL / TWA value
depending on setting in Access Code 4.
If ppm symbol is blinking then STEL or TWA time
interval is not reached yet.
Available only if "PPM" measuring
units are set.
Step Function Note
