Installation
PrimaX
12
GB
Sensors
The device operates with a 4 – 20 mA output signal.
As an optional feature additional modules are available for these configurations of
PrimaX transmitter:
For more information on the HART module chapter 4.7.
3 Installation
The device should be installed where gas leaks are expected. The installation po-
sition depends on the gas density, either in the upper area of the room under the
ceiling for gases lighter than air or close to the ground for gases heavier than air.
Also consider how air movement may affect the ability of the device to detect gas.
The display on the front of the instrument must always be clearly visible, the view
must not be obstructed.
Description PrimaX P PrimaX I
Detection of toxic gases X X
Detection of oxygen X X
Detection of combustible gases X
Modules PrimaX P PrimaX I
HART module X X
HART + Relays module X -
HART+ Relays module
with galvanically isolated analogue output
X-
Before beginning the installation, check that the delivered components
are complete and correct, referring to the shipping documents and the
sticker on the shipment carton.
When preparing the assembly, make sure that the mounting arrange-
ment is correct for the particular device.
