Figure 22 Junction Box
Figure 23 Junction Box Electrical Connections
3.6 Electrical Power Connections
3.6.1 Electrical Warnings - Read before Connecting Power
WARNING!
• Before wiring the S5000 transmitter, disconnect the power source supplying the transmitter and ensure no hazardous
atmosphere present; otherwise, electrical shock or ignition of hazardous gases could occur.
• Install wiring in accordance with the electrical code of the country in use, the local authority having jurisdiction and these
installation instructions, as applicable.
23
US 3 Installation
