MSA S5000 User Manual

Gas Type Range Concentration Cylinder P/N P/N with
CalibrationKit
Calibration Kit
Only
(NoCylinder)
Carbon
Dioxide
(IR700)
0-2000 1000 PPM2 1400262-41A
N/A
1400270-2
0-5000 2500 PPM2 1400262-16A 1400270-2
0-10000 5000 PPM2 1400262-37A 1400270-2
0-30000 15000 PPM2 1400262-27A 1400270-2
0-50000 25000 PPM2 1400262-40A 1400270-2
Note that for zeroing of the IR700 sensor, zero gas is required.
Air contains CO
2
and cannot be used. Nitrogen is
recommended as the zero gas. The nitrogen cylinder P/N is
1400262-17.
1
Balance Air
2
Balance Nitrogen
3
Chlorine Dioxide sensor calibration with 10 PPM NO2 and a Span Value of 1.4 PPM
4
Hydrogen Fluoride sensor calibrated with 10 PPM HCL and Span Value of 6 PPM
5
For 0-20% Passive Cat Bead sensors deployed for nonane please calibrate with P/N 711054 (0.1% Propane in Air) and set
span value to 10.2. For 0-20% Cat Bead sensors deployed for butanol, please calibrate with PN 711054 (0.1% Propane in Air)
and set the span value to 8.7.
Flow Rates
CALKIT1 and 1400270-2 = 1 liter/min
1400152-1 and 1400154-1 = 0.5 liter/min
CALKIT2 = 0.25 liter/min
CALKIT3 = 0.5 liter/min, SST Regulator, used with HCL
CALKIT4 Demand Regulator, used with sampling
systems
5.2 Calibration Frequency
The frequency of calibration gas testing depends on the operating time, chemical exposure, and type of sensor. Especially in
new installations or applications, it is recommended that the first sensors be calibrated more often to establish the sensor
performance in this particular environment.
For this, record the "as found" and "as left" values and track the percent adjustment over time. Then, gradually extend
calibration intervals until the percent adjustment is greater than the expected accuracy of the sensor.
5.3 Calibration Frequency for XCell Sensors with TruCal (H
2
S & CO only)
WARNING!
Certain conditions may prevent the performance of Diffusion Supervision and/or TruCal testing. If such a condition persists for
90 days, the XCell sensor with TruCal will recommend a calibration which is communicated through the transmitter display
66
US 5 Calibration
