10 Appendix: HART Specific Information
The S5000 Gas Monitor is available with an optional HART (Highway Addressable Remote Transducer) output
communications protocol. With this option, the S5000 complies with HART Protocol Revision7 and uses the 16-bit
manufacturer and device codes. This document specifies all the device specific features and documents HART Protocol
implementation details (e.g., the Engineering Unit Codes supported). These specifications assume the reader is somewhat
familiar with HART Protocol requirements and terminology.
This specification is a technical reference for HART-capable HOST Application Developers, System Integrators and
knowledgeable End Users. It also provides functional specifications (e.g., commands, enumerations and performance
requirements) used during Field Device deployment, maintenance, testing, and operations. It is recommended that the 4-
20mA output be the primary gas monitoring signal. The HART signal can be the secondary method.
Table 23 Device Identification
Manufacturer Name General Monitors Model Name S5000 Transmitter
HART ID Code 227 (0xE3) Device Type Code 115 (0x73)
HART Protocol -Revision 7 Device Revision 1
Number of Device Variables 1/2
Physical Layers Supported FSK, Wireless
Physical Device Category Transmitter
The 3.5mA version of the IR400 is not compatible with the S5000.
98
