15
Installation
US
SM5000 Sampling Module - DC Pump Model
(1) Remove all protective packaging plugs and/or caps from the Pump Sampling Module:
gas inlet
exhaust ports.
(2) Attach a 1/4-inch (6.35 mm) OD sample tubing to the flow block sample inlet fitting on the gas monitor
(see Fig. 1). Ensure tubing is compatible with the sampled gas.
(3) Route the sample tubing to the area to be monitored.
NOTE: Do not run the sample tubing in water or across areas of vibration, doorways, man ways or
access ways; otherwise, a sample tubing leak or tripping hazard may result.
(4) Using suitable hardware (not supplied):
a) fasten the sample tubing to supports.
b) fasten the end of the sample tubing and sample inlet in the monitoring area.
NOTE: The sample inlet should be pointed downward to prevent dirt and water from entering the
sample tubing line.
(5) Install the provided end-of-line filter at the end of the sample tubing, if applicable.
(6) Check for leaks along the entire length of the sample tubing line. Any leak will dilute the gas sample
from the area of interest and give a lower than actual gas reading.
(7) The in-line filter will trap water and block the flow.
2.5 Exhaust Line Placement
(1) Attach a 1/4-inch (6.35 mm) OD sample tubing to the exhaust outlet fitting on the Pump Sampling
Module unit.
(2) Route the exhaust tubing into a safe area where the gas sample can be vented. Avoid any sharp bends
or elbows. Route the tubing to allow any collected water to drain.
NOTE: The maximum exhaust tubing length is 20 feet (6 meters).
NOTE: Do not run the exhaust tubing in water or across areas of vibration or across doorways, man
ways or access ways; otherwise, a leak in the exhaust tubing or a tripping hazard may result.
(3) Fasten the exhaust tubing to supports using suitable hardware (not supplied).
(4) Fasten the end of the exhaust tubing in the area of interest by using suitable hardware (not supplied).
NOTE: Exhaust inlet should be pointed downward to prevent dirt and water from entering the exhaust
tubing line.
(5) Check for leaks along entire length of the exhaust tubing line.
