16 INSTALLATION INSTRUCTIONS
MSD • WWW.MSDPERFORMANCE.COM • (915) 857-5200 • FAX (915) 857-3344
CHRYSLER IGNITIONS Wiring a Chrysler Electronic Ignition using Magnetic Pickup Trigger.
FROM ORIGINAL
COIL TERMINAL
+
BLACK (M-)
ORANGE (M+)
CHRYSLER MODULE
LEAVE DISCONNECTED
DISTRIBUTOR
VIOLET
GREEN
INDICATES CONNECTION
+
(NOT USED)
COVER
WITH TAPE
ORANGE
BLACK
GRAY
TACH OUTPUT
RED
WHITE
HARNESS
MAGNETIC
PICKUP
CONNECTOR
GREEN (-)
VIOLET (+)
DIGITAL 6AL
REV
LIMITER
FORD IGNITIONS Wiring a Ford TFI with Harness, PN 8874.
COIL
+
ORANGE
BLACK
MSD HARNESS PN 8874
FACTORY HARNESS
(UNPLUGGED FROM COIL)
RED
WHITE
BLACK
ORANGE
MAGNETIC PICKUP
(NOT USED)
GRAY
TACH OUTPUT
GREEN (-)
VIOLET (+)
RED
WHITE
BLACK
ORANGE
DIGITAL 6AL
REV
LIMITER
NOTE: If not using the TFI Harness, refer to the DuraSpark
wiring diagram on page 15 (top diagram).
