MSD 6A 6201 - Chrysler Ignitions: Late Model Dodge Wiring; MSD Systems: Dual Ignition Setup

INSTALLATION INSTRUCTIONS 17
MSD • WWW.MSDPERFORMANCE.COM • (915) 857-5200 • FAX (915) 857-3344
CHRYSLER IGNITIONS Wiring a Late Model Dodge with 2-pin connector.
BLACK/GRAY
OR GRAY
GREEN/
ORANGE
FROM IGNITION AMPLIFIER
(ORIGINAL COIL WIRE)
ORANGE (TO COIL +)
BLACK (TO COIL -)
MAGNETIC PICKUP
(NOT USED)
GRAY
TACH OUTPUT
RED
WHITE
FROM IGNITION KEY
(ORIGINAL COIL WIRE)
GREEN (-)
VIOLET (+)
INDICATES CONNECTION
DIGITAL 6AL
REV
LIMITER
NOTE: Original wiring must be cut.
MSD offers two direct plug-in
harnesses; PN 8889 for '90-
'97 and PN 8884 for '98-'03.
DUAL
MAGNETIC
PICKUP
DISTRIBUTOR
TO DISTRIBUTOR
HARNESS PN 8860
AUTOMATIC COIL
SELECTOR
PN 8210
MAG
MAG
+
MAG
+
MAG
HARNESS PN 8860
(NOT USED)
ORANGE
BLACK
GRAY
TACH OUTPUT
RED
WHITE
GREEN (-)
VIOLET (+)
(NOT USED)
ORANGE
BLACK
MAGNETIC
PICKUP
GRAY
TACH OUTPUT
RED
WHITE
GREEN (-)
VIOLET (+)
SPDT SWITC
PN 8807
TO SWITCHED
12 VOLTS
MAGNETIC
PICKUP
DIGITAL 6AL
REV
LIMITER
DIGITAL 6AL
REV
LIMITER
MSD SYSTEMS Wiring a Complete Dual MSD Ignition Setup.
