MSD 6A 6201 - Aftermarket Components: Mallory Magnetic Pickup; Aftermarket Components: Pertronix Ignitor Kit

INSTALLATION INSTRUCTIONS 19
MSD • WWW.MSDPERFORMANCE.COM • (915) 857-5200 • FAX (915) 857-3344
AFTERMARKET COMPONENTS Wiring a Mallory 9000 Series using Magnetic Pickup.
BLK/ORANGE
BLK/GREEN
MALLORY
DISTRIBUTOR
+
(NOT USED)
GREEN
GREEN
PN 8860
HARNESS
VIOLET
VIOLET
ORANGE
BLACK
GRAY
TACH OUTPUT
RED
WHITE
FROM IGNITION KEY
(ORIGINAL COIL WIRE)
DIGITAL 6AL
REV
LIMITER
AFTERMARKET COMPONENTS Wiring to a Pertronix Ignitor Kit.
If you did not nd a schematic to match your application, or if you need assistance, please
contact MSD Tech at (915) 855-7123.
RED
RED
IGNITION KEY
TO 12V
BLACK
DISTRIBUTOR
WITH
PERTRONIX
WHITE
ORANGE
BLACK
MAGNETIC PICKUP
(NOT USED)
GRAY
TACH OUTPUT
GREEN (-)
VIOLET (+)
DIGITAL 6AL
REV
LIMITER
