MSI 5000V Master2 Series - Quick Components Guide

MS-9638 Server Board
2-2
Quick Components Guide
Important
CAUTION!!! Please note that the CPU1/CPU2 VRM & memory/south bridge
area should be respectively kept under 105
o
C and 85
o
C. To ensure system
stability, always protect the system with proper cooling. Otherwise, overheat-
ing may damage the system.
JLANDIS1/2,
p.2-16
SYSFAN5/6/2,
p.2-12
FDD1, p.2-10
COM2,
p.2-14
IDE1,
p.2-10
SATA0~5,
p.2-11
JUSB1/2,
p.2-14
J9, p.2-16
CPU, p.2-3
PCI-Class
Slots, p.2-17
JBAT1,
p.2-15
JPWR1, p.2-8
CPUFAN1/2,
p.2-12
JBIOS1, p.2-16
DDR2 DIMMs, p.2-6
SYSFAN1,
p.2-12
JPWR2, p.2-8
Back Panel
I/O, p.2-9
JCI1, p.2-12
JACT2/1,
p.2-13
JFP1, p.2-13
SAS5~8,
p.2-11
SAS1~4,
p.2-11
SYSFAN3/4,
p.2-12
