MS-9638 Server Board
2-10
Connectors
Floppy Disk Drive Connector: FDD1
The mainboard provides a standard floppy disk drive connector.
FDD1
ATA100 Hard Disk Connector: IDE1
The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 66/100 controller that
provides PIO mode 0~4, Bus Master, and Ultra DMA 66/100 function. You can connect
hard disk drives, CD-ROM and other IDE devices.
Important
If you install two hard disks on cable, you must configure the second drive to
Slave mode by setting its jumper. Refer to the hard disk documentation
supplied by hard disk vendors for jumper setting instructions.
IDE1
9638v3.0-2.p65 2007/5/8, 下午 01:5410
