MSI 694T Pro - Integrated Peripherals; Onchip IDE Channel0;Onchip IDE Channel1; IDE Prefetch Mode

AWARD
®
BIOS Setup
4-15
Integrated Peripherals
Onchip IDE Channel0 Enabled
Onchip IDE Channel1 Enabled
IDE Prefetch Mode Enabled
Primary Master PIO Auto
Primary Slave PIO Auto
Secondary Master PIO Auto
Secondary Slave PIO Auto
Primary Master UDMA Auto
Primary Slave UDMA Auto
Secondary Master UDMA Auto
Secondary Slave UDMA Auto
Init Display First AGP
Onchip USB Enabled
USB Keyboard Support Disabled
USB Mouse Support Disabled
IDE HDD Block Mode Enabled
Onboard FDD Controller Enabled
Onboard Serial Port 1 Auto
Onboard Serial Port 2 Auto
UART 2 Mode Standard
X IR Function Duplex Half
X TX,RX inverting enable No, Yes
Onboard Parallel Port 378/IRQ7
Onboard Parallel Mode Normal
X ECP Mode Use DMA 3
X Parallel Port EPP Type EEP 1.9
Onchip Sound Enabled
Sound Blaster Disabled
SB I/O Base Address 22QH
SB IRQ Select IRQ 5
SB DMA Select DMA1
MPU-401 Disabled
MPU-401 I/O Address 330-333H
Game Port (200-207H) Enabled
Onchip Modem Enabled
Item Help
Menu Level >
↑ ↓ → ← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults
CMOS Setup Utility - Copyright(C) 1984-2001 Award Software
Integrated Peripherals
OnChip IDE Channel0/Onchip IDE Channel1
The integrated peripheral controller contains an IDE interface with
support for two IDE channels. Select Enabled to activate each channel
separately. The settings are: Enabled and Disabled.
IDE Prefetch Mode
This item is used to Enabled or Disabled the IDE Read/Write Prefetch
buffer. This buffer is used to store data for faster performances.
