Chapter 4
4-24
IRQs Activity Monitoring
IRQ3 (COM 2) Enabled
IRQ4 (COM 1) Enabled
IRQ5 (LPT 2) Enabled
IRQ6 (Floppy Disk) Enabled
IRQ7 (LPT 1) Enabled
IRQ8 (RTC Alarm) Disabled
IRQ9 (IRQ2 Redir) Disabled
IRQ10 (Reserved) Disabled
IRQ11 (Reserved) Disabled
IRQ12 (PS/2 Mouse) Enabled
IRQ13 (Coprocessor) Enabled
IRQ14 (Hard Disk) Enabled
IRQ15 (Reserved) Disabled
Item Help
Menu Level >
↑ ↓ → ← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults
The following is a list of IRQ’s, Interrupt ReQuests, which can be exempted
much as the COM ports and LPT ports above can. When an I/O device
wants to gain the attention of the operating system, it signals this by
causing an IRQ to occur. When the operating system is ready to respond to
the request, it interrupts itself and performs the service.
When set On, activity will neither prevent the system from going into
a power management mode nor awaken it.
