MSI A320M-A PRO - Jaud1: 前置音频接口; Jcom1: 串行端头接口; Jtpm1: Tpm 模组接口

13
󶵪󱠁󴚰󸷈 󶵪󱠁󴚰󸷈
󱶝󶹌󹰭󹴜󳲞󲁅
󴨡󳲞󲁅󱯬󸜡󳞅󸶚󳲞󱶝󶹌󹬻󴍆󱚗󹰭󹴜󳳨󲷔
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
󱛒󸂈󶖒󲤆󳲞󲁅
󴨡󳲝󲁅󱯬󸜡󳞄󸶚󳲝󲁗󸸉󱛒󸂈󶖒󲁅󲁗󵭡󳳧󴞙
1
2 10
9
1 DCD 2 SIN
3 SOUT 4 DTR
5 Ground 6 DSR
7 RTS 8 CTS
9 RI 10 No Pin
󴟜󶵪󳲞󲁅
󴨡󳲞󲁅󴄡󵭡󴌟󸶚󳲞󲹂󾆈󳎦󲁙󴟜󶵪󸝠󲀐󶽰󲹂󾆈󳎦󲁙󳩿󱱧󱟧󷝊󳗈󴉣󲣙󶵬󷓀󲅈
󵭡󴲥
1
2 14
13
1 LPC Clock 2 3V Standby power
3 LPC Reset 4 3.3V Power
5 LPC address & data pin0 6 Serial IRQ
7 LPC address & data pin1 8 5V Power
9 LPC address & data pin2 10 No Pin
11 LPC address & data pin3 12 Ground
13 LPC Frame 14 Ground
