MSI A320M-A PRO - Rear I;O Panel

6



 
Off No link
Yellow Linked
Blinking Data activity

 
Off 10 Mbps connection
Green 100 Mbps connection
Orange 1 Gbps connection

PS/2 Keyboard
PS/2 Mouse
LAN
DVI-D
USB 2.0
USB 3.2 Gen1
Line-in
Mic in
Line-out

To configure 7.1-channel audio, you have to connect front audio I/O module to JAUD1
connector and follow the below steps.
 Click on the  to open the dialog
below.
 Select .
 Plug your speakers to audio jacks on rear and front I/O panel. When you plug into
a device at an audio jack, a dialogue window will pop up asking you which device
is current connected.
