Specifications
ThunderboltM3 Card Specification
Chipset Intel Thunderbolt 3 controller
External connector
y 2 x thunderbolt 3 port (type C)
 up to 40 Gbps for Thunderbolt devices
 up to 10 Gbps for USB 3.1 devices
y 1 x 5 pin TB header
y 2 x DisplayPort input ports
 DisplayPort 1.2 specification
Interface PCIe 3.0 x4 (depends on MB supportive slot)
Capabilities Supports DisplayPort 1.2 with max, 4K x 2K @60/24 Hz
Form factor 3.35 inch x 4.11 inch (8.5 cm x 10.4 cm)
JCORSAIR1 Connector Specification
Supporting CORSAIR RGB Products Maximum connection
Lighting Node PRO LED Strip
20*
* In the case of 20% brightness
HD120 RGB Fan 6
SP120 RGB Fan 6
LL120 RGB Fan 6
