MSI MPG Z690 EDGE WIFI DDR4 User Manual

8
Specifications
Continued from previous page
Internal Connectors
 
 
 6x SATA 6Gb/s connectors
 
 
 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
 
 
 
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1xTPM module connector
 1x Clear CMOS jumper
 1x Tuning controller connector
 1x TBT connector (Supports RTD3)
LED Features
 
 
 1x EZ LED Control switch
 4x EZ Debug LED
I/O Controller NUVOTON NCT6687D Controller Chip
Hardware Monitor
 CPU/ System/ Chipset temperature detection
 CPU/ System/ Pump fan speed detection
 CPU/ System/ Pump fan speed control
Form Factor
 ATX Form Factor
 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Continued on next page

MSI MPG Z690 EDGE WIFI DDR4 Specifications

General

Form Factor	atx
OS Compatibility	windows 10, windows 11 home
Chipset	z690
Chipset Compatibility	intel
Processor Socket	socket lga 1700
Processor Compatibility	intel, intel core i9, intel core i7, intel core i5, intel core i3
RAID	raid 0, raid 1, raid 5
Multi-GPU	crossfire
Memory Type	ddr4
Memory Speeds	1r 2133/ 2666/ 2933/ 3200 mhz (by jedec & por)
SATA Connectors	6x sata 6g
Wireless Standard	ac
Wireless Networking Standard	wi-fi 6
Wireless Connectivity	bluetooth, wi-fi
USB Ports	2 x usb-c 3.2, 7 x usb-a 3.2, 2 x usb-a 2.0
Audio Ports	1x front audio (jaud)
Audio Channels	7.1
M.2 Slots	4

Weight and Dimensions

Width	243.84 millimeters
