MSI MS-14L1 - Mainboard; Mainboard Disassembly

2-22 2-23
Mainboard
Mainboard Disassembly
1. Disconnect the keyboard cable connector, speaker cable connector. and camera
cable connector from the mainboard.
2. Loosen the screws that secure the mainboard with a cross type screwdriver.
3. Remove the mainboard.
