MSI MS-14L1 - LCD Display Module; LCD Bezel Disassembly

2-30 2-31
Disassembly and Assembly
LCD Display Module
LCD Bezel Disassembly
1. Use a cross type screwdriver to loosen the screws that secure the right and left
hinge caps located on the lower rightand leftbottom corner of the LCD display,
and then remove both hinge caps.
2. Use a pry tool to separate the bezel of the LCD display with care.
