MSI MS-S0121 - Page 28

2-12
Hardware Setup MS-S0121
Hardware Setup MS-S0121
Serial ATA Connector: SATA1 ~ SATA6
This connector is a high-speed Serial ATA interface port. Each connector can
connect to one Serial ATA device.
Important
Please do not fold the SATA cable into a 90-degree angle. Otherwise, data loss
may occur during transmission.
