2-13
Hardware Setup MS-S0121
Serial Port Connector: COM2
This connector is a 16550A high speed communications port that sends/receives
16 bytes FIFOs. You can attach a serial device to it.
1.DCD
3.SOUT
1
0.No
P
in
5
.Ground
7.
RT
S
9.RI
8.CT
S
6.DS
R
4.DT
R
2.SI
N
Front USB Connector: JUSB1 ~ JUSB4
This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for
connecting high-speed USB interface peripherals such as USB HDD, digital cam-
eras, MP3 players, printers, modems and the like.
1.VC
C
3.USB0
-
10.NC
5.USB0
+
7
.Ground
9.No
Pi
n
8
.Ground
6.USB1
+
4.USB1
-
2.VC
C
USB 2.0 Bracket
(Optional)
Important
Note that the pins of VCC and GND must be connected correctly to avoid pos-
sible damage.
