MSI PM8M2-V Series User Manual

1-2
MS-7071 M-ATX Mainboard
Mainboard Specifications
CPU
h Supports Intel
®
Pentium 4 / Celeron-D in the 775-land package
h Supports 800/533MHz FSB
(For the latest information about CPU, please visit http://www.msi.com.tw/program/
products/mainboard/mbd/pro_mbd_cpu_support.php)
Chipset
h VIA
®
P4M800 chipset
- 64 bit P4 processor FSB I/F (800MHz)
- 64 bit DDR SDRAM memory I/F (333/400MHz)
- 32 bit AGP I/F (66MHz) for 8x/4x mode
- Supports 8X V-Link
h VIA
®
VT8237R Plus chipset
- Integrated Hardware Sound Blaster/Direct Sound AC97 audio
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- Supports USB 2.0 up to 8 ports
- ACPI & PC2001 compliant enhanced power management
Main Memory
h Supports four memory banks using two 184-pin DDR DIMMs
h Supports up to 2GB DDR333/400 SDRAMs
h Supports 2.6v DDR SDRAM
(For the updated supporting memory modules, please visit http://www.msi.com.tw/
program/products/mainboard/mbd/pro_mbd_trp_list.php )
Slots
h One AGP (Accelerated Graphics Port) 3.0 8X slot
h Two PCI 2.2 32-bit PCI bus slots (support 3.3v/5v PCI bus interface)
On-Board IDE
h An IDE controller integrated in the VIA VT8237R Plus chipset providing IDE HDD/
CD-ROM with PIO, Bus Master and Ultra DMA 66/100/133 operation modes
h Support 2 Serial ATA 150 ports.
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
- 1 serial port, Com1
- 1 parallel port supports SPP/EPP/ECP mode
- 8 USB 2.0/1.1 ports (Rear * 4 / Front * 4)
- 1 Line-In/Line-Out/Mic
- 1 RJ45 connector
- 1VGA
