3-9
BIOS Setup
[Disabled] Shows the POST messages at boot.
IOAPIC Function
This field is used to enable or disable the APIC (Advanced Programmable
Interrupt Controller). Due to compliance with PC2001 design guide, the system
is able to run in APIC mode. Enabling APIC mode will expand available IRQ
resources for the system. Settings: [Enabled], [Disabled].
MPS Table Version
This field allows you to select which MPS (Multi-Processor Specification) ver-
sion to be used for the operating system. You need to select the MPS version
supported by your operating system. To find out which version to use, consult
the vendor of your operating system. Settings: [1.4], [1.1].
Execute Bit Support
Execute Bit Support allows the processor to classify areas in memory by
where application code can execute and where it cannot. When a malicious
worm attempts to insert code in the buffer, the processor disables code
execution, preventing damage or worm propagation. Setting options: [Enabled],
[Disabled].
C1E Support
When The CPU ID>0F40 and is above 533MHz/2.8GHz or 800MHz/3.6GHz, you
can enable C1E Support to lower the CPU power consumption while idle.
Settings: [Enabled], [Disabled].
Set Limit CPUID MaxVal to 3
Set this item to Enabled when using an older OS like Windows NT. Set to
Disabled with Windows XP.
Boot Sequence
Press <Enter> and the following sub-menu appears:
1st/2nd/3rd Boot Device
These items allow you to set the sequence of boot devices where BIOS
attempts to load the operating system.
MSI Reminds You...
Available settings for “1st/2nd/3rd Boot Device” vary depending
on the bootable devices you have installed. For example, if you
did not install a floppy drive, the setting “Floppy” will not show up.
