3-15
BIOS Setup
USB Device Legacy Support
Set to [Enabled] if you need to use any USB 1.1/2.0 device in the operating
system that does not support or have any USB 1.1/2.0 driver installed, such as
DOS. Set to [Disabled] only if you want to use any USB device other than the
USB mouse. Setting options: [Disabled], [Enabled].
Onboard LAN Controller
The item enables or disables the onboard LAN controller. Setting options:
[Enabled], [Disabled].
Onboard LAN Option ROM
The item enables or disables the initialization of the onboard LAN Boot ROMs
during bootup. Selecting [Disabled] will speed up the boot process. Setting
options: [Enabled], [Disabled].
AC97 Controller
This item is used to enable or disable the onboard AC97 (Audio Codec) controller.
Selecting [Enabled] allows the mainboard to enable the onboard AC97 controller.
Disable the function if you want to use other controller cards to connect an
audio device. Settings: [Disabled] and [Enabled].
IDE Devices Configuration
Press <Enter> to enter the sub-menu and the following screen appears:
OnChip SATA
This setting is used to specify the SATA controller. The settings are:
[Disabled], [Enabled].
SATA Mode
This setting is used to specify the SATA mode. Setting options: [IDE], [RAID].
PCI IDE BusMaster
Set this option to [Enabled] to specify that the IDE controller on the PCI local
bus has bus mastering capability. Settings options: [Disabled], [Enabled].
OnChip IDE Channel 0/1
The integrated peripheral controller contains a IDE interface with support
for two IDE channels. Select [Enabled] to activate the IDE interface. Set-
tings options: [Disabled], [Enabled].
