MSI PRO B760M-A DDR4 II User Manual

16
Continued from previous column
M.2 SSD Slots
 2x M.2 slots (Key M)
• M2_1 slot (From CPU)
• Supports up to PCIe 4.0 x4
• Supports 2242/ 2260/ 2280 storage devices
• M2_2 slot (From B760 chipset)
• Supports up to PCIe 4.0 x4
• Supports SATA 6Gb/s
• Supports 2242/ 2260/ 2280 storage devices
RAID
 Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Audio
Realtek® ALC897 Codec
 7.1-Channel High Definition Audio
LAN  1x Realtek® 8125BG 2.5Gbps LAN controller
Power Connectors
 1x 24-pin ATX main power connector
 1x 8-pin +12V power connector
 1x 4-pin ATX 12V power connector
Internal USB
Connectors
 1x USB 3.2 Gen 1 5Gbps Type-C front panel port (From
B760 chipset)
 2x USB 3.2 Gen 1 5Gbps connectors (From Hub-GL3523)
• Supports additional 4 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 connectors (From Hub-GL805G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin water-pump fan connector
 2x 4-pin system fan connectors
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
 1x Serial port connector
Jumpers
 1x Clear CMOS jumper
Continued on next column
