Back Panel Connectors

Item Description

1 PS/2 Mouse/ Keyboard combo port

2 DisplayPort

3 USB 3.2 Gen 1 5Gbps Type-A ports (From B760 chipset)

4 2.5 Gbps LAN port

5 Audio jacks

6 USB 2.0 Type-A ports (From B760 chipset)

HDMI™ ports

8 USB 3.2 Gen 2 10Gbps Type-A ports (From B760 chipset)

22 33 44 55

66 77 88

Questions and Answers:

Need help?

Do you have a question about the MSI PRO B760M-A DDR4 II and is the answer not in the manual?

MSI PRO B760M-A DDR4 II Specifications

General

Chipset	Intel B760
Form Factor	Micro ATX
Memory Type	DDR4
Memory Slots	4
Maximum Memory	128GB
CPU Socket	LGA 1700
Video Outputs	1 x HDMI 2.1, 1 x DisplayPort 1.4
Storage Interface	4x SATA 6Gb/s, 2x M.2
Network	Realtek RTL8125BG 2.5Gbps LAN
Audio	Realtek ALC897 7.1-Channel High Definition Audio
Memory Speed	Up to 5333 MHz (OC)
USB Ports	6x USB 3.2, 6x USB 2.0
