A-8
MS-7151 ATX Mainboard
Select the speaker by clicking it to test its functionality. The one you select will
light up and make testing sound. If any speaker fails to make sound, then check
whether the cable is inserted firmly to the connector or replace the bad speakers with
good ones. Or you may click the “Auto Test” button to test the sounds of each
speaker automatically.
Subwoofer
Front Right
Rear Right
Center
Front Left
Rear Left
Side Left Side Right
3. While you are testing the speakers in 8-Channel / 6-Channel Mode, if the
sound coming from the center speaker and subwoofer is swapped, you
should select Swap Center/Subwoofer Output to readjust these two
channels.

MSI RX480 Neo2 MS-7151 Specifications

General

Model	RX480 Neo2 MS-7151
Socket	Socket 939
Memory Type	DDR
Maximum Memory Supported	4GB
PCI-E x16 Slots	1
IDE	2 x ATA 133
Form Factor	ATX
Memory Slots	4
SATA	4
PCI Slots	3
