MSI X58 Pro-E seres - Quick Components Guide

2-2
Hardware Setup ▍
MS-7522
Hardware Setup ▍
MS-7522
RE SET
Clr
CMOS
Quick coMponentS guide
Back Panel,
p.2-9
CPU, p.2-3 DDR3, p.2-7
JPWR1, p.2-11
IDE1, p.2-14
JCI1,p.2-16
JUSB1~3, p.2-17
JCOM1, p.2-18
JPWR2, p.2-11
CPUFAN1, p.2-15
J1394_1, p.2-16
CPU_CLK1, p.2-20
CLR_CMOS1, p.2-21
RESET1, p.2-21
POWER1, p.2-21
JCD1, p.2-16
JAUD1, p.2-17
JFP1, JFP2, p.2-15
PCIE Slot, p.2-22
PCI Slot, p.2-22
SYSFAN2, p.2-15
SYSFAN1~3, p.2-15
SATA1~7, p.2-14
JSP1, p.2-19
