MeMory
These DIMM slots are used for nstallng memory modules.
For more nformaton on compatble components, please vst
http://www.ms.com/ndex.php?func=testreport
DDR3
240-pn, 1.5V
48x2=96 pn 72x2=144 pn
Memory Populaton Rules
Please refer to the followng llustratons for memory populaton rules.
Sngle-Channel mode
When you have only one memory module, please always nsert t nto the DIMM_A0
󰘰rst (as way 1 shown n below).
Installed
Empty
1
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
Dual-Channel mode
In Dual-Channel mode, the memory modules can transmt and receve data wth two
data bus lnes smultaneously. Enablng Dual-Channel mode can enhance the system
performance. When you have two memory modules, please always nsert them nto
the DIMM_A0 & DIMM_B0 (as way 2 shown n below).
2
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
