Hardware Setup ▍
MS-7522
Hardware Setup ▍
MS-7522
Trple-Channel mode
In Trple-Channel mode, the memory modules can transmt and receve data wth
three data bus lnes smultaneously. Enablng Three-Channel mode can enhance the
best system performance. When you have three or more memory modules, please
always nsert them as the way 3/ 4/ 5/ 6 (shown n below) to get the best system
performance.
3
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
4
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
5
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
6
DIMM_A1
DIMM_A0
DIMM_B1
DIMM_B0
DIMM_C1
DIMM_C0
