Hardware Setup
MS-7522
2-25
Hardware Setup
MS-7522
Led StatuS indicatorS
RESET
Clr
CMOS
DIMM warning LED
PCIE LED
Power LED
Suspend LED
CPU Phase LEDs
PCIE LED
PCIE LED
PCIE LED
PCIE LED
PCI LED
PCI LED
CPU Phase LEDs
These LEDs ndcate the current CPU power phase mode. Follow the nstructons
below to read.
5 of the LEDs wll lght blue when CPU s n 5 phase power mode.
4 of the LEDs wll lght blue when CPU s n 4 phase power mode.
3 of the LEDs wll lght blue when CPU s n 3 phase power mode.
2 of the LEDs wll lght blue when CPU s n 2 phase power mode.
1 of the LEDs wll lght blue when CPU s n 1 phase power mode.
