Page 24 MTI Part Number 7001-0040
Revision 3.1 August 7, 2014
TOOLS Menu – Remote Control Panel Continued
DC OFFSET – Enter the desired amount of DC voltage offset of the signal.
PHASE OFFSET – Enter the desired phase offset in degrees
(relative to Channel B signal).
SIGNAL TYPE – Use the drop-down feature to select between
VOLTS and Single Ended (SE) or Differential (DE) CHARGE type
of signal.
SWEEP MODE SETTINGS - The 1500 can generate a signal on channel B whose
frequency constantly varies over a specified period of time. This feature is useful
for simulating acceleration or deceleration runs of machinery.
START FREQUENCY – This value defines the frequency at
which the SWEEP will begin.
STOP FREQUENCY – This value defines the frequency at which
the SWEEP will stop.
FREQUENCY UNITS – Use the drop down tool to select either
Hz (hertz or cycles per second) or RPM (Revolutions per Minute).
SWEEP TIME – Enter the period of time (in seconds) in which the
sweep will be performed.
CHANNEL B SETTINGS
FUNCTION – This may be set to SINE, TRIANGLE,
SAWTOOTH, SQUARE, PULSE, TACH or TTL signals using the
drop down menu selector.
PULSE MODE – The 1500 produces a single pulse
occurring at the same frequency or at a ratio of the
Channel A frequency. The pulse duty cycle can be
programmed from 3% to 100% of the period.
TACH MODE – The 1500 can produce a series of pulses
simulating a multi-tooth gear speed signal.
