IMPORTANT NOTICE: Please contact a qualified electrician to carry out the installation. We will not be held
responsible for damage as a result of a wrong connection which may cause injury or death. Please note that
the monitor displays the apparent Power (VA) and not the Active Power (Watts).
“Before making any connection to a Live
Circuit”, connect all clamp sensors to
transmitter.
*** IMPORTANT NOTE ***
This is very important because when current is
flowing through the sensor clamp, the resulting
voltage induced in the secondary can be quite high.
The sensor needs to be fitted to the live feed cable. You should not force
the cable to fit.
2. Push the release cap to open the sensor.
3. Select the correct feed cable and then place the feed cable
into the top of the sensor.
4. Close the sensor. The sensor is secure when a
“click” is heard.
