MTS Sensors Temposonics V SSI R Series

Temposonics
®
R-Series V SSI
Operation Manual
I 32 I
Electrical connection
Connection type 1 × M16 male connector (7 pin) or cable output
Operating voltage +12…30 VDC ±20 % (9.6…36 VDC)
Power consumption 1.2 W typical
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −36 VDC
Overvoltage protection Up to 36 VDC
