Installing Cables
MTS Exceed™ Series 40 Product Manual Installation
49
J3 Interlock
This connector should be connected to the safety system (Enclosure switch). If
the safety system is not used?a pin jumper should be connected to clear the
system interlock. The enclosure switch has two NC contacts. One must be
connected between Pin 1 and Pin 4. The other should be connected between Pin 2
and Pin 5.
J4 Encoder
The J4 connector should be connected to J11 Encoder Insight connector, the
cable from J4 to J11 must be connected when using the J10 Encoder User
connector for system operation.
J5 Digital I/O
Digital I/O signals include three optically isolated inputs, three optically isolated
outputs, and 12 V power. Functions of each digital input or output are software
selectable. A typical example might be connecting an external switch; see
“Additional Digital I/O Information” on page 81. Only DIN1 and DOUT2 & 3
are available for external use; DIN2 & DOUT1 are used for Fault status
communicates with the software; DIN3 is used for Enclosure door switch status.
Pin assignments are as follows:.
P
IN
S
IGNAL
1 Transmit+
2 Transmit-
3 +12 V
4 INTLK+
5 INTLK-
6 Analog GND
7 Receive+
8 Receive-
P
IN
S
IGNAL
1 DIN1+
2 DIN2+
3 DIN3+
4 DOUT1+
5 DOUT2+
6 DOUT3+
7 No Contact
8
+12 V
9 DIN1-
10 DIN2-
0Exceed product manual.book Page 49 Wednesday, August 27, 2014 2:55 PM
