MTS Exceed™ Series 40 Product Manual
50
Installing Cables
Installation
J6 and J7 Monitor
Two monitor connectors are provided. There are several possible uses for analog
monitor outputs: external data acquisition, tuning, troubleshooting, and so forth.
For tuning, it is desirable to monitor command an feedback, or command and
error, simultaneously while changing the controller parameters. Therefore, two
monitor outputs are provided. Specifics for these connectors are:
• Analog +/-10.5 V
• Calibrated to +/-10 V
• 16-bit resolution minimum
• BNC connectors
J8 and J9 DC
Conditioner
The J8 connector should be connected to J14 DC Cond Insight connector, the J9
connector should be connected to J15 DC Cond Insight connector. The cable
from J8 to J14 must be connected when using the J12 DC Cond User connector
for system operation, and the cable from J9 to J15 must be connected when using
the J13 DC Cond User connector for system operation.
J10 Encoder User
This connector is intended for encoder-based transducers. Specifics for this
connector are:
• Quantity: 2 encoder signal acquisition channel.
• Power: +5 V +/- 0.25 V at 100 mA max
• Signals: Quadrature A and B with index I
• Logic: Differential receivers (can connect single ended)
• Maximum Rate: 100,000 lines/sec = 400,000 counts/sec.
Pin assignments are as follows:
11 DIN3-
12 DOUT1-
13 DOUT2-
14 DOUT3-
15 Analog GND
P
IN
S
IGNAL
1 TEDS+_1
2 A+_1
3 A-_1
4 +5_1
5 I+_1
6 I_1
7 Analog GND_1
0Exceed product manual.book Page 50 Wednesday, August 27, 2014 2:55 PM
