Installing Cables
MTS Exceed™ Series 40 Product Manual Installation
51
J11 Encoder Insight The J11 connector should be connected to J4 Encoder connector,The cable from
J11 to J4 must be connected when using the J10 Encoder User connector for
system operation.
J12 and J13 DC
Conditioner User
Two external DC conditioner connectors are provided. Up to two
external,transducers can be connected such as: axial or transverse extensometers,
biaxial extensometer, auxiliary load cells, pressure gages, LVDTs or strain-gaged
components.
Pin assignments are as follows:
8 B+_1
9 B-_1
10 TEDS-_1
11 No Contact
12 No Contact
13 No Contact
14 No Contact
15 No Contact
16 TEDS+_2
17 A+_2
18 A-_2
19 +5_2
20 I+_2
21 I_2
22 Analog GND_2
23 B+_2
24 B-_2
25 TEDS-_2
P IN S IGNAL
1 EX+
2 EX-
3 No Contact
4 FB+
5 FB-
6 No Contact
7 No Contact
0Exceed product manual.book Page 51 Wednesday, August 27, 2014 2:55 PM
