MTS Systems Level Plus User Manual

Modbus Register Data Address Data Description
30222 0221 Tank 5, NSVP Low Word
30223 0222 Tank 5, Mass High Word
30224 0223 Tank 5, Mass Low Word
30225 0224 Reserved
30226 0225 Reserved
30251 0250 Tank 6, Level 1 High Word (x 1000)
30252 0251 Tank 6, Level 1 Low Word (x 1000)
30253 0252 Tank 6, Level 2 High Word (x 1000)
30254 0253 Tank 6, Level 2 Low Word (x 1000)
30255 0254 Tank 6, Average Temperature (x 100)
30256 0255 Tank 6, RTD 1 (x 100)
30257 0256 Tank 6, RTD 2 (x 100)
30258 0257 Tank 6, RTD 3 (x 100)
30259 0258 Tank 6, RTD 4 (x 100)
30260 0259 Tank 6, RTD 5 (x 100)
30261 0260 Tank 6, Alarm Status
30262 0261 Reserved
30263 0262 Tank 6, GOVP High Word
30264 0263 Tank 6, GOVP Low Word
30265 0264 Tank 6, GOVI High Word
30266 0265 Tank 6, GOVI Low Word
30267 0266 Tank 6, GOVT High Word
30268 0267 Tank 6, GOVT Low Word
30269 0268 Tank 6, GOVU High Word
30270 0269 Tank 6, GOVU Low Word
30271 0270 Tank 6, NSVP High Word
30272 0271 Tank 6, NSVP Low Word
30273 0272 Tank 6, Mass High Word
30274 0273 Tank 6, Mass Low Word
30275 0274 Reserved
30276 0275 Reserved
30301 0300 Tank 7, Level 1 High Word (x 1000)
30302 0301 Tank 7, Level 1 Low Word (x 1000)
30303 0302 Tank 7, Level 2 High Word (x 1000)
30304 0303 Tank 7, Level 2 Low Word (x 1000)
30305 0304 Tank 7, Average Temperature (x 100)
30306 0305 Tank 7, RTD 1 (x 100)
30307 0306 Tank 7, RTD 2 (x 100)
30308 0307 Tank 7, RTD 3 (x 100)
30309 0308 Tank 7, RTD 4 (x 100)
30310 0309 Tank 7, RTD 5 (x 100)
30311 0310 Tank 7, Alarm Status
30312 0311 Reserved
104
