15 Analog Parameters
Use the number keys to select the analog output number to edit and press the ENTER key. The
eight available analog output channels are referenced as analog output #1 to analog output #8.
The analog output #1 assignment is shown. To change this assignment press the MODE key.
Enter the tank number that analog output #1 will be assigned to, or enter “0” to disable the ana-
log output.
The default output value for analog output #1 is shown. This control parameter defines the state
of the analog output channel when system errors occur. System errors include uninitialized data
(after power-up), invalid volume data and tank gauge errors. Press the MODE key to change the
default output value. The available choices are 4 ma, 20 ma and LAST VAL.
The analog output #1 is assigned to TANK #1, PRODUCT. Press the MODE key to change the
analog control parameter. Available parameters are:
• Interface level • GOVP • NSVP
• Product level • GOVI • MASS
• Temperature • GOVT • GOVU
ANALOG OUTPUT #1
ON SYS ERR = 4 ma
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
ASSIGN OUTPUT #1
TO TANK # --
ENTER TANK NUMBER OR
‘0’ TO DISABLE OUTPUT
ANALOG OUTPUT #1
ASSIGNED TO TANK #1
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
SELECT ANALOG OUTPUT
TO EDIT: (1-8)
‘Enter’ TO CONTINUE
52
