The control parameter value corresponding to the 4mA output limit is displayed. Press the MODE
key to change this value.
Use the number keys to type a new 4mA value and press the ENTER key.
The control parameter value corresponding to the 20mA output limit is displayed. Press the
MODE key to change this value.
Use the number keys to type a new 20mA value and press the ENTER key. Repeat the above
sequence for each analog output (1-8).
NOTE:
Negative offsets may be entered by pressing the +/- key
after number entry.
OUTPUT #1, TANK #1
20 MA=------- in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
OUTPUT #1, TANK #1
20 MA= 100.000 in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
OUTPUT #1, TANK #1
4 MA=-------- in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
OUTPUT #1, TANK #1
4 MA= 10.000 in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
OUTPUT #1, TANK #1
ASSIGNED TO PRODUCT
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
53
