3 Model Number Information
Model Number: Level Plus DDA Monitor
NOTE
All Level Plus DDA Monitors include:
• 8 alarm contact outputs
• EIA485A or EIA232C communications
• Factory installed safety barriers to permit DDA tank
gauge installation (up to 8) in hazardous areas
(Class I, II, III, Division 1, Groups C, D, E, F and G)
• Option of (8) 4-20 milliamp outputs
8
3
LEVEL PLUS DDA MONITOR
POWER SUPPLY INPUT
0 = 115 V
1 = 230 V
ENCLOSURE
1 = NEMA 1 Indoor Enclosure (w/4-20 mA outputs)
2 = NEMA 1 Indoor Enclosure
4 = NEMA 4X Indoor/Outdoor Enclosure (w/ 4-20mA outputs)
5 = NEMA 4X Indoor/Outdoor Enclosure
7 = NEMA 7 Explosion-proof Enclosure (w/4-20 mA outputs)
8 = NEMA 7 Explosion-proof Enclosure
COMMUNICATIONS PROTOCOL
0 = MTS ASCII Communication Protocol
1 = Modbus RTU Communication Protocol
2 = Modbus ASCII Communication Protocol
COMMUNICATIONS
2 = EIA232C Communications
4 = EIA485A Communications
SAFETY BARRIERS
3 = 3 Safety Barriers
To Next Page
