13 Tank Gauge and Tank Parameters
Enter the desired tank numbers to be polled during measurement mode. Type the respective tank
number once to turn on the multiplex assignment (i.e. enable tank gauge to be polled). Type the
respective tank number again to turn off the multiplex assignment. Press the ENTER key to con-
tinue.
Some examples of DDA tank gauge switch settings are showns as follows.
NOTE
The user must program (set) the communication
address switch inside the DDA tank gauge to match
the desired tank channel in the Level Plus monitor.
The Level Plus monitor will always poll the DDA tank
gauge at communication address C0 hex (192 deci-
mal) for Tank # 1, C1 hex (193 decimal) for Tank
#2, C2 hex for Tank #3, etc. See the MTS DDA tank
gauge operation manual (MTS #550164) for addi-
tional information on setting the DDA gauge com-
munication address switch.
TYPE TANK# TO TOGGLE
MULTIPLEX ASSIGNMENT
1 - - - - - - -
‘Enter’ TO CONTINUE
43
