MTS Systems Level Plus - Level Offset Calibration

Figure 8.4 Example DDA Tank Gauge Address Switch Settings
Enter the tank number you wish to edit and press the ENTER key.
SELECT TANK NUMBER
TO EDIT: (1-8)
‘Enter’ TO CONTINUE
Binary Value of Each Switch
Address = C1 HEX = 193 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C2 HEX = 194 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C3 HEX = 195 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C4 HEX = 196 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C5 HEX = 197 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C6 HEX = 198 Decimal
1 2 3 4 5 6 7 8 9
ON
Address = C7 HEX = 199 Decimal
1 2 3 4 5 6 7 8 9
ON
Base Address = C0 HEX = 192 Decimal
1 2 3 4 5 6 7 8 9
ON
32 16 8 4 2 1
