Alphanumeric Tank Label
The alphanumeric tank label can be up to 7 characters long and comprised of any of the
alphanumeric characters in the list shown in the next section. The default tank label is
TANK#1: as shown below in the example screen (where x is the given tank #). Press the
MODE key to change the current tank label.
The tank label edit screen is shown below:
Editing is performed as follows:
• Use the “9” and “0” keys to move the edit cursor left or right, respectively.
• Use the “1” and “2” keys to scroll through the available alphanumeric characters (see list
below). The “1” key moves forward through the list one character at a time where as the
“2” key moves backwards through the list one character at a time.
• Use the “6” and “7” keys to advance or back up through the character list 5 characters at
a time.
• Press the ‘Enter’ key when the edit session is complete
• Alphanumeric Character List: A-Z, 0-9, : , # , < , >, blank, @
Level Resolution
The tank gauge level resolution is shown in the units you have previously selected dur-
ing system parameter editing. To change the selected resolution press the MODE key or
the ± key. Press the ENTER key to continue. The available selections are:
• Decimal Inches: 0.1, 0.01, 0.001
• Decimal Feet: 0.01, 0.001, 0.0001
• Fractional Inches: 1/16, 1/32, 1/64
• Millimeters: 1.0, 0.1, 0.025
• Meters: 0.001, 0.0001, 0.000025
NOTE
The complete 7 character alphanumeric tank label
can only be displayed in display mode #5. This is
due to screen size limitations when displaying volume
or individual RTD temperature information. The vol-
ume and individual RTD display modes can only dis-
play the 5th, 6th, and 7th characters of the 7 charac-
ter tank level. Tank labels should be created that
show uniqueness for the 3 characters (i.e. TANK589,
TANK621, etc.)
< Edit Key
Definitions
TANK#1: 1,2 = +1,-1
$$
6,7 = +5,-5
9,0 = < >
‘Enter’ TO CONTINUE
Edit Cursor >
CURRENT LABEL FOR
TANK#1 = TANK#1:
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
45
