Map 2: Registers arranged by data type
Modbus Register Data Address Data Description
30401 0400 Tank 1, Level 1 High Word (x 1000)
30402 0401 Tank 1, Level 1 Low Word (x 1000)
30403 0402 Tank 2, Level 1 High Word (x 1000)
30404 0403 Tank 2, Level 1 Low Word (x 1000)
30405 0404 Tank 3, Level 1 High Word (x 1000)
30406 0405 Tank 3, Level 1 Low Word (x 1000)
30407 0406 Tank 4, Level 1 High Word (x 1000)
30408 0407 Tank 4, Level 1 Low Word (x 1000)
30409 0408 Tank 5, Level 1 High Word (x 1000)
30410 0409 Tank 5, Level 1 Low Word (x 1000)
30411 0410 Tank 6, Level 1 High Word (x 1000)
30412 0411 Tank 6, Level 1 Low Word (x 1000)
30413 0412 Tank 7, Level 1 High Word (x 1000)
30414 0413 Tank 7, Level 1 Low Word (x 1000)
30415 0414 Tank 8, Level 1 High Word (x 1000)
30416 0415 Tank 8, Level 1 Low Word (x 1000)
30451 0450 Tank 1, Level 2 High Word (x 1000)
30452 0451 Tank 1, Level 2 Low Word (x 1000)
30453 0452 Tank 2, Level 2 High Word (x 1000)
30454 0453 Tank 2, Level 2 Low Word (x 1000)
30455 0454 Tank 3, Level 2 High Word (x 1000)
30456 0455 Tank 3, Level 2 Low Word (x 1000)
30457 0456 Tank 4, Level 2 High Word (x 1000)
30458 0457 Tank 4, Level 2 Low Word (x 1000)
30459 0458 Tank 5, Level 2 High Word (x 1000)
30460 0459 Tank 5, Level 2 Low Word (x 1000)
30461 0460 Tank 6, Level 2 High Word (x 1000)
30462 0461 Tank 6, Level 2 Low Word (x 1000)
30463 0462 Tank 7, Level 2 High Word (x 1000)
30464 0463 Tank 7, Level 2 Low Word (x 1000)
30465 0464 Tank 8, Level 2 High Word (x 1000)
30466 0465 Tank 8, Level 2 Low Word (x 1000)
30501 0500 Tank 1, Average Temperature (x 100)
30502 0501 Tank 2, Average Temperature (x 100)
30503 0502 Tank 3, Average Temperature (x 100)
30504 0503 Tank 4, Average Temperature (x 100)
30505 0504 Tank 5, Average Temperature (x 100)
30506 0505 Tank 6, Average Temperature (x 100)
30507 0506 Tank 7, Average Temperature (x 100)
30508 0507 Tank 8, Average Temperature (x 100)
30551 0550 Tank 1, RTD 1 (x 100)
